Part 1: Various Desktop Robot

General desktop robot, it is most commonly used and cost-effective.

High quality Janome robot, high accuracy and long life.

Multi-axis articulated robot integrated with soldering units can become a premium soldering robot. It is compact and lightweight.

Part 2: Various Temperature Control System

Weller temperature control system

Temperature Controller

Weller® Temperature control system + Weller® heating element + customized soldering unit.

80+ types of replacement tips, can be customized. ⇒ Soldering Tips

[table]

Input Voltage, AC90~264V 50/60Hz

Input air-pressure, 4~5kg/cm²

Solder wire, Φ0.4mm~Φ1.6mm

Temperature Range, 0~500°C

Heater Wattage, 150W

Outer air switch, optional

Weight, 3.5KG

Solder feeder weight, 0.8KG

Soldering unit weight, 0.5KG

[/table]

Apollo Seiko LUNA temperature control system

[table]

Model, LUNA/Apollo Seiko®

Input Voltage, AC90~264V 50/60Hz

Input air-pressure, 4~5kg/cm²

Solder wire, Φ0.4mm~Φ1.6mm

Replacement Tips, DCS/DCN Series Tips

Parameters Memory, 7 units (point soldering 4 units/slide soldering 3 units)

Temperature Range, 0~500°C

Heater Wattage, 100W or 130W

Soldering Step, 9 steps

Standby Tip Temperature, 250°C (adjustable)

Outer air switch, optional

Weight, 3.5KG

Solder feeder weight, 0.8KG

Soldering unit weight, 0.5KG

[/table]

QUICK® temperature control system

[table]

Input Voltage,100~240V AC

Solder wire, Φ0.4mm~Φ1.6mm

Soldering Tip, 911G Series tips

Temperature Range, 50~500°C

Heater Wattage, 150W

Weight, 3KG

[/table]

I don't know how to choose

Usually, it depends on the budget. If the product need to soldering is premium & expensive, you should not buy cheap machines because they can’t meet the high requirement soldering applications.

Pre-sales communication is very important,

How to buy the machine?

If you are experienced operator, just tell us what kind of soldering robot you need (desktop size, axis qty, temperature controller type) and we will offer proposal to you. For experienced operators you need to adjust the machine by yourself.

If you are a newbie, the easiest thing is to send PCB sample to us, and then we custom made the proposal accordingly. You only need to make a little settings when receive the machine.

What training do you provide?

Training Methods

  1. Learning through instruction manual or video course
  2. if manual is not enough, ask for technical support by phone or mail
  3. Request for in-house training (paid service)

What is the warranty term?

Warranty Policy:

  • 3 years for main machine (not include consumable items)
  • Lift-time paid maintenance or repair
  • Life-time free technical support
